Question: A 250-V, 4-pole, wave-wound d.c. series motor has 782 conductors on itsarmature. It has armature and series field resistance of 0.75 ohm. The motor takesa current of 40 A. Estimate its speed and gross torque developed if it has a flux per pole of 25 mWb Answer: Step 1 Mechanical Engineering homework question answer, step 1, image 1 Mechanical Engineering homework question answer, step 1, image 2 Step 2 Mechanical Engineering homework question answer, step 2, image 1 Step 3 Mechanical Engineering homework question answer, step 3, image 1

Link will be apear in 30 seconds.

Well done! you have successfully gained access to Decrypted Link.

https://www.chegg.com/homework-help/questions-and-answers/current-10-mh-inductance-t-01-cos-104t--find-voltage-stored-energy-functions-time-assume-r-q22895051

Question:

The current through a 10-mH inductance is i(t) = 0.1 cos(104t) A. Find
the voltage and stored energy as functions of time. Assume that the references for
v(t) and i(t) have the passive configuration. (The angle is in radians.)

Answer v(t) = −10 sin(104t) V, w(t) = 50 cos2(104t) μJ. ( I want to see the process)

---

Answer:
